| size_t | get_max_packet_size () |
| |
| float | get_setup_priority () const override |
| |
| void | setup () override |
| |
| void | loop () override |
| |
| void | dump_config () override |
| |
| void | set_auto_cal (bool auto_cal) |
| |
| void | set_bandwidth (SX127xBw bandwidth) |
| |
| void | set_bitrate (uint32_t bitrate) |
| |
| void | set_bitsync (bool bitsync) |
| |
| void | set_coding_rate (uint8_t coding_rate) |
| |
| void | set_crc_enable (bool crc_enable) |
| |
| void | set_deviation (uint32_t deviation) |
| |
| void | set_dio0_pin (InternalGPIOPin *dio0_pin) |
| |
| void | set_frequency (uint32_t frequency) |
| |
| void | set_mode_rx () |
| |
| void | set_mode_tx () |
| |
| void | set_mode_standby () |
| |
| void | set_mode_sleep () |
| |
| void | set_modulation (uint8_t modulation) |
| |
| void | set_pa_pin (uint8_t pin) |
| |
| void | set_pa_power (uint8_t power) |
| |
| void | set_pa_ramp (uint8_t ramp) |
| |
| void | set_packet_mode (bool packet_mode) |
| |
| void | set_payload_length (uint8_t payload_length) |
| |
| void | set_preamble_errors (uint8_t preamble_errors) |
| |
| void | set_preamble_polarity (uint8_t preamble_polarity) |
| |
| void | set_preamble_size (uint16_t preamble_size) |
| |
| void | set_preamble_detect (uint8_t preamble_detect) |
| |
| void | set_rst_pin (InternalGPIOPin *rst_pin) |
| |
| void | set_rx_floor (float floor) |
| |
| void | set_rx_start (bool start) |
| |
| void | set_shaping (uint8_t shaping) |
| |
| void | set_spreading_factor (uint8_t spreading_factor) |
| |
| void | set_sync_value (const std::vector< uint8_t > &sync_value) |
| |
| void | run_image_cal () |
| |
| void | configure () |
| |
| SX127xError | transmit_packet (const std::vector< uint8_t > &packet) |
| |
| void | register_listener (SX127xListener *listener) |
| |
| Trigger< std::vector< uint8_t >, float, float > * | get_packet_trigger () const |
| |
| float | get_actual_setup_priority () const |
| |
| void | set_setup_priority (float priority) |
| |
| virtual float | get_loop_priority () const |
| | priority of loop().
|
| |
| void | call () |
| |
| virtual void | on_shutdown () |
| |
| virtual void | on_safe_shutdown () |
| |
| virtual bool | teardown () |
| | Called during teardown to allow component to gracefully finish operations.
|
| |
| virtual void | on_powerdown () |
| | Called after teardown is complete to power down hardware.
|
| |
| uint8_t | get_component_state () const |
| |
| void | reset_to_construction_state () |
| | Reset this component back to the construction state to allow setup to run again.
|
| |
| bool | is_in_loop_state () const |
| | Check if this component has completed setup and is in the loop state.
|
| |
| virtual void | mark_failed () |
| | Mark this component as failed.
|
| |
| void | mark_failed (const char *message) |
| |
| void | disable_loop () |
| | Disable this component's loop.
|
| |
| void | enable_loop () |
| | Enable this component's loop.
|
| |
| void | enable_loop_soon_any_context () |
| | Thread and ISR-safe version of enable_loop() that can be called from any context.
|
| |
| bool | is_failed () const |
| |
| bool | is_ready () const |
| |
| virtual bool | can_proceed () |
| |
| bool | status_has_warning () const |
| |
| bool | status_has_error () const |
| |
| void | status_set_warning (const char *message="unspecified") |
| |
| void | status_set_error (const char *message="unspecified") |
| |
| void | status_clear_warning () |
| |
| void | status_clear_error () |
| |
| void | status_momentary_warning (const std::string &name, uint32_t length=5000) |
| |
| void | status_momentary_error (const std::string &name, uint32_t length=5000) |
| |
| bool | has_overridden_loop () const |
| |
| void | set_component_source (const char *source) |
| | Set where this component was loaded from for some debug messages.
|
| |
| const char * | get_component_source () const |
| | Get the integration where this component was declared as a string.
|
| |
| bool | should_warn_of_blocking (uint32_t blocking_time) |
| |
| | SPIDevice () |
| |
| | SPIDevice (SPIComponent *parent, GPIOPin *cs_pin) |
| |
| void | spi_setup () override |
| |
| void | spi_teardown () override |
| |
| void | set_spi_parent (SPIComponent *parent) |
| |
| void | set_cs_pin (GPIOPin *cs) |
| |
| void | set_data_rate (uint32_t data_rate) |
| |
| void | set_bit_order (SPIBitOrder order) |
| |
| void | set_mode (SPIMode mode) |
| |
| uint8_t | read_byte () |
| |
| void | read_array (uint8_t *data, size_t length) |
| |
| void | write (uint16_t data, size_t num_bits) |
| | Write a single data item, up to 32 bits.
|
| |
| void | write_cmd_addr_data (size_t cmd_bits, uint32_t cmd, size_t addr_bits, uint32_t address, const uint8_t *data, size_t length, uint8_t bus_width=1) |
| |
| void | write_byte (uint8_t data) |
| |
| void | transfer_array (uint8_t *data, size_t length) |
| | Write the array data, replace with received data.
|
| |
| void | transfer_array (std::array< uint8_t, N > &data) |
| |
| uint8_t | transfer_byte (uint8_t data) |
| |
| void | write_byte16 (uint16_t data) |
| | Write 16 bit data.
|
| |
| void | write_array16 (const uint16_t *data, size_t length) |
| | Write an array of data as 16 bit values, byte-swapping if required.
|
| |
| void | enable () |
| |
| void | disable () |
| |
| void | write_array (const uint8_t *data, size_t length) |
| |
| void | write_array (const std::array< uint8_t, N > &data) |
| |
| void | write_array (const std::vector< uint8_t > &data) |
| |
| | SPIClient (SPIBitOrder bit_order, SPIMode mode, uint32_t data_rate) |
| |
| bool | spi_is_ready () |
| |
| void | set_release_device (bool release) |
| |
| void | set_write_only (bool write_only) |
| |
|
| void | configure_fsk_ook_ () |
| |
| void | configure_lora_ () |
| |
| void | set_mode_ (uint8_t modulation, uint8_t mode) |
| |
| void | write_fifo_ (const std::vector< uint8_t > &packet) |
| |
| void | read_fifo_ (std::vector< uint8_t > &packet) |
| |
| void | write_register_ (uint8_t reg, uint8_t value) |
| |
| void | call_listeners_ (const std::vector< uint8_t > &packet, float rssi, float snr) |
| |
| uint8_t | read_register_ (uint8_t reg) |
| |
| virtual void | call_loop () |
| |
| virtual void | call_setup () |
| |
| virtual void | call_dump_config () |
| |
| void | set_interval (const std::string &name, uint32_t interval, std::function< void()> &&f) |
| | Set an interval function with a unique name.
|
| |
| void | set_interval (const char *name, uint32_t interval, std::function< void()> &&f) |
| | Set an interval function with a const char* name.
|
| |
| void | set_interval (uint32_t interval, std::function< void()> &&f) |
| |
| bool | cancel_interval (const std::string &name) |
| | Cancel an interval function.
|
| |
| bool | cancel_interval (const char *name) |
| |
| void | set_retry (const std::string &name, uint32_t initial_wait_time, uint8_t max_attempts, std::function< RetryResult(uint8_t)> &&f, float backoff_increase_factor=1.0f) |
| | Set an retry function with a unique name.
|
| |
| void | set_retry (uint32_t initial_wait_time, uint8_t max_attempts, std::function< RetryResult(uint8_t)> &&f, float backoff_increase_factor=1.0f) |
| |
| bool | cancel_retry (const std::string &name) |
| | Cancel a retry function.
|
| |
| void | set_timeout (const std::string &name, uint32_t timeout, std::function< void()> &&f) |
| | Set a timeout function with a unique name.
|
| |
| void | set_timeout (const char *name, uint32_t timeout, std::function< void()> &&f) |
| | Set a timeout function with a const char* name.
|
| |
| void | set_timeout (uint32_t timeout, std::function< void()> &&f) |
| |
| bool | cancel_timeout (const std::string &name) |
| | Cancel a timeout function.
|
| |
| bool | cancel_timeout (const char *name) |
| |
| void | defer (const std::string &name, std::function< void()> &&f) |
| | Defer a callback to the next loop() call.
|
| |
| void | defer (const char *name, std::function< void()> &&f) |
| | Defer a callback to the next loop() call with a const char* name.
|
| |
| void | defer (std::function< void()> &&f) |
| | Defer a callback to the next loop() call.
|
| |
| bool | cancel_defer (const std::string &name) |
| | Cancel a defer callback using the specified name, name must not be empty.
|
| |
Definition at line 44 of file sx127x.h.
Public Member Functions inherited from esphome::Component
